凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (06-018) - KNOTTER HEAD ASSEMBLY - CONTINUED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
37-138
|
[1] |
DOWEL,3/16" x 1/2"
|
CAS
PIN, 3/16 x 1/2 Superseded by part number: 88251
|
| 2. |
1712835
|
[1] |
HOOK
|
CAS
BILL ASSEMBLY Superseded by part number: 700734488
|
| 3. |
163-47
|
[2] |
SCREW,Hex, #10 - 32 x 1/2", Gr 5
|
CAS
Superseded by part number: 86637658
|
| 4. |
6613624
|
[1] |
WASHER, LOCK
|
CAS
TAB
|
| 5. |
700718710
|
[1] |
KNIFE
|
CAS
twine
|
| 6. |
700102136
|
[1] |
KNIFE
|
CAS
BASE, twine
|
| 7. |
495-11053
|
[1] |
WASHER,1/2", SAE
|
CAS
Special Superseded by part number: 87364, 72187259
|
| 8. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 9. |
425-118
|
[1] |
NUT,1/2"-20, G5
|
CAS
Superseded by part number: 280963
|
| 10. |
7852593
|
[2] |
SHIM,15mm ID x 21mm OD x 1mm Thk
|
CAS
MACHINERY, 9/16 x 20 GA. Superseded by part number: 84007145
|
| 11. |
700122799
|
[1] |
ROLLER
|
CAS
spherical
|
| 12. |
7852577
|
[1] |
RING, SNAP
|
CAS
RING SNAP retaining
|
| 13. |
6591580
|
[1] |
SHAFT
|
CAS
twine, Includes: Ref. 14
|
| 14. |
238-5016
|
[1] |
O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro
|
CAS
Superseded by part number: 128359
|
