神钢零件查询(F4HFE613F B002) - ENGINE - 5801743987 - 47424030 (7/14-) (10.250.AD) - TURBOCHARGER LUBE LINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
350 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2857015 | [1] | HYD CONNECTOR,Hex, M12 x 1.5 x 6.7mm ID x 32mm L | TOR Superseded by part number: |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 3. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 4. | 4899108 | [1] | O-RING,0.364mm ID x 0.07mm Width | TOR Superseded by part number: 17277981 |
| 5. | 84351985 | [1] | FLEXIBLE HOSE | FAR Superseded by part number: |
| 6. | 4895089 | [1] | PLUG,0.886" L | TOR |
