凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (06-030) - RESET ARM ASSEMBLY, 700138218 RESET ARM ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
100-1175
|
[2] |
SNAP RING,#75, Ext
|
CAS
Superseded by part number: 72186587, 129164
|
| 2. |
700138225
|
[1] |
ROLLER,50.8mm OD x 19mm L
|
HFI
CLUTCH
|
| 3. |
B18254
|
[1] |
NEEDLE BEARING,Needle, 25.4mm ID x 31.75mm OD x 25.4mm W
|
CAS
NEEDLE
|
| 4. |
700714166
|
[1] |
SPRING
|
CAS
extension
|
| 5. |
700138219
|
[1] |
ARM
|
HFI
ASSEMBLY, Includes: Ref. 3
|
| 6. |
700138224
|
[1] |
ANVIL
|
HFI
CLUTCH, knotter
|
