神钢零件查询(F4HFE613F B002) - ENGINE - 5801743987 - 47424030 (7/14-) (55.015.AA) - ELECTRONIC CONTROL UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
832 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84499733 | [1] | ECU | GI |
| 2. | 504297839 | [1] | BRACKET | TOR |
| 3. | 17935001 | [4] | SELF-TAP SCREW,Hex Flng, M5.5 x 1.8 x 45mm | TOR |
| 8. | 2852101 | [2] | FLANGE BOLT,Hex, M6 x 16mm | TOR Superseded by part number: 18137825 |
| 9. | 2852818 | [2] | SCREW,Hex, M6 x 1 x 30mm | SM Superseded by part number: 16586025 |
| 10. | NS | [6] | NOT SERVICED | BASIsolator |
| 11. | NS | [3] | NOT SERVICED | BASScrew |
| 12. | NS | [1] | NOT SERVICED | BASCover |
| 14. | 4858609 | [2] | WASHER,Brass | TTF |
| 15. | NS | [2] | NOT SERVICED | BASScrew |
