纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (5.652[03]) - ROPS CAB - WINDSHIELD WASHER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
370 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76033166 | [1] | SUPPORT | LEC |
| 2. | 79030150 | [1] | SECURING STRAP | LEC |
| 3. | 76033167 | [1] | WINDSHIELD WASH RESERVOIR | LEC Superseded by part number: 76066606 |
| 4. | 79095451 | [4] | NOZZLE | LEC |
| 5. | 79095815 | [1] | HOSE,4.00 mm ID x 800.00 mm | LEC Superseded by part number: 19052980 |
| 6. | 79095816 | [3] | HOSE | LEC Superseded by part number: 19044986 |
| 7. | 79095817 | [2] | HOSE,4.00 mm ID x 3500.00 mm | LEC Superseded by part number: 19052980 |
| 8. | 79097787 | [2] | TEE | LEC |
| 9. | 16043331 | [3] | SCREW,Hex, M8 x 1.25 x 18mm, Cl 10.9, Full Thd | LEC |
| 10. | 16100821 | [3] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 11. | 14496531 | [6] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 12. | 79013422 | [5] | CABLE TIE,145mm L | LEC |
