| 1. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Pump Mount
|
| 3. |
9623917
|
[1] |
GUARD
|
ZED
|
| 4. |
87711118
|
[1] |
SHIELD
|
NH
|
| 5. |
619284
|
[3] |
CLAMP,23.8mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
Superseded by part number: 87029955
|
| 6. |
513309
|
[2] |
HOSE CLAMP,1-1/16" - 2", Worm
|
NH
|
| 7. |
86633920
|
[2] |
SPACER,10.32mm ID x 19.05mm OD x 11.1mm L
|
NH
|
| 8. |
9706921
|
[2] |
HOSE CLAMP,12.7mm - 35mm
|
NH
Superseded by part number: 87625624
|
| 9. |
120103
|
[4] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
| 10. |
322358
|
[5] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 11. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 12. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 13. |
43138
|
[1] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 14. |
43140
|
[3] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 15. |
120041
|
[2] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 16. |
86512446
|
[5] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 17. |
87016
|
[4] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 18. |
140045
|
[11] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
100016
|
[11] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
9604653
|
[1] |
HOSE
|
NH
|
| 21. |
87494317
|
[1] |
BRACKET
|
NH
|
| 22. |
529070
|
[5] |
CABLE TIE,368.3mm L
|
NH
CABLE STRAP
|
| 23. |
9604651
|
[1] |
HOSE
|
NH
|
| 24. |
PL
|
[2] |
PROCURE LOCALLY
|
BAS
Edging
|
| 25. |
9604650
|
[1] |
HOSE,25.40 mm ID x 1220.00 mm, SAE 100R3
|
NH
|
| 26. |
9604654
|
[1] |
HOSE,19.00 mm ID x 2700.00 mm, SAE 100 R3
|
NH
|
| 27. |
86629783
|
[1] |
V-BELT,95.00" L
|
NH
|
| 28. |
86640952
|
[1] |
SPRING
|
NH
|
