凯斯零件查询(110) - CASE IH QUADROBALE BALER (1/96-12/98) (002) - FRICTION-TYPE OVERRUN CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
739 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8301650
|
[1] |
CLUTCH
|
R
Friction clutch
|
| 2. |
9410990
|
[1] |
RING, LOCKING
|
R
Adjusting ring
|
| 3. |
8302960
|
[1] |
KIT
|
R
Spring kit M = 1050 Nm
|
| 4. |
9411041
|
[4] |
LINING
|
R
Friction plate
|
| 5. |
9411060
|
[1] |
DRIVEN PLATE
|
R
Drive plate
|
| 6. |
9411070
|
[1] |
DRIVEN PLATE
|
R
Drive plate
|
| 7. |
9217950
|
[1] |
GASKET
|
R
Seal ring
|
| 8. |
933089R1
|
[2] |
SNAP RING,M60, Ext
|
IH
Circlip 60x2 Superseded by part number: 370027
|
| 9. |
2118460
|
[2] |
BEARING
|
R
Grvd.ball bearing 61812
|
| 10. |
9217960
|
[2] |
WASHER
|
R
Back-up washer
|
| 11. |
8173050
|
[1] |
HUB
|
R
|
| 12. |
8142280
|
[2] |
BUCKET TOOTH KEY
|
R
Stop key
|
| 13. |
8142290
|
[2] |
SPRING
|
R
Flat spring
|
| 14. |
9217941
|
[1] |
HUB
|
R
Coupler
|
| 15. |
2382772
|
[1] |
GASKET
|
R
Shaft seal ring As 55x 80x 8
|
| 16. |
9411100
|
[1] |
RING
|
R
|
| 17. |
8147661
|
[1] |
HOUSING
|
R
Clutch housing
|
