沃尔沃零件查询MD11; MD11C; MD11D; MD17; MD17C; MD17DCooling SystemCooling System, Induction- and Exh Manifold Spec 867577, -677, -678: BEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
179 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
829930
|
[1] |
Exhaust pipe
|
|
| 2. |
192211
|
[3] |
Expansion plug
|
|
| 3. |
833598
|
[2] |
Gasket
|
|
| 4. |
940129
|
[6] |
Hexagon screw
|
|
| 5. |
955894
|
[6] |
Washer
|
|
| 8. |
829592
|
[1] |
Shut-off cock
|
|
| 9. |
829916
|
[1] |
Thermostat housing
|
|
| 10. |
838501
|
[1] |
Thermostat
|
76°C
|
| 11. |
416033
|
[1] |
Sealing ring
|
|
| 12. |
940132
|
[2] |
Hexagon screw
|
|
| 13. |
941907
|
[2] |
Spring washer
|
|
| 14. |
829911
|
[1] |
Heat exchanger
|
|
| 15. |
829972
|
[1] |
Gasket
|
|
| 16. |
|
|
|
|
| 17. |
829987
|
[1] |
End plate
|
|
| 18. |
829988
|
[1] |
End plate
|
|
| 19. |
829989
|
[1] |
Gasket
|
|
| 20. |
829990
|
[1] |
Bracket
|
|
| 21. |
829991
|
[1] |
Bar
|
|
| 22. |
941906
|
[3] |
Spring washer
|
|
| 23. |
963105
|
[3] |
Lock nut
|
|
| 24. |
100223
|
[2] |
Hexagon screw
|
L=55mm
|
| 25. |
960141
|
[4] |
Washer
|
|
| 27. |
840510
|
[1] |
Coolant pipe
|
|
| 27A. |
952627
|
[1] |
Clamp
|
For pipe 840510.
|
| 27B. |
840199
|
[1] |
Anchorage
|
|
| 27C. |
840200
|
[1] |
Anchorage
|
|
| 28. |
829901
|
[1] |
Connecting pipe
|
|
| 29. |
829932
|
[1] |
Coolant pipe
|
|
| 30. |
829905
|
[1] |
Coupling piece
|
|
| 31. |
829915
|
[1] |
Spacer ring
|
|
| 32. |
180211
|
[1] |
Hollow screw
|
|
| 33. |
957178
|
[1] |
Gasket
|
|
| 34. |
927963
|
[1] |
Plug
|
|
| 35. |
829933
|
[1] |
Coolant pipe
|
|
| 36. |
829920
|
[1] |
Insert nipple
|
|
| 37. |
|
|
|
|
| 38. |
829847
|
[1] |
Pump housing
|
|
| 39. |
829899
|
[1] |
Bracket
|
|
| 40. |
829923
|
[1] |
Gasket
|
|
| 41. |
829953
|
[1] |
Circulation pump
|
|
| 42. |
941906
|
[1] |
Spring washer
|
|
| 43. |
955275
|
[1] |
Hexagon screw
|
|
| 44. |
829935
|
[1] |
Coolant pipe
|
|
| 45. |
829936
|
[1] |
Coolant pipe
|
|
| 46. |
955897
|
[2] |
Washer
|
|
| 47. |
955345
|
[2] |
Hexagon screw
|
L=55mm
|
| 48. |
1276040
|
[1] |
Expansion tank
|
|
| 49. |
840172
|
[1] |
Bracket
|
|
| 50. |
829653
|
[2] |
Spacer sleeve
|
|
| 51. |
940142
|
[2] |
Hexagon screw
|
L=30mm
|
| 52. |
941907
|
[2] |
Spring washer
|
|
| 53. |
840171
|
[1] |
Clamp
|
|
| 54. |
956092
|
[1] |
Cross recessed screw
|
|
| 55. |
941906
|
[1] |
Spring washer
|
|
| 56. |
942700
|
[1] |
Hose
|
L=605mm
|
| 57. |
942700
|
[1] |
Hose
|
L=295mm
|
| 58. |
942700
|
[1] |
Hose
|
L=40mm
|
| 59. |
840179
|
[1] |
Hose coupling
|
|
| 60. |
829917
|
[1] |
Hose coupling
|
|
| 61. |
829934
|
[1] |
Coolant pipe
|
|
| 62. |
940280
|
[1] |
Spring washer
|
(955924) L=16mm
|
| 63. |
941907
|
[1] |
Spring washer
|
|
| 64. |
943369
|
[1] |
Rubber hose
|
L=95mm
|
| 65. |
943472
|
[2] |
Hose clamp
|
|
| 66. |
829928
|
[1] |
Hose connection
|
|
| 67. |
418445
|
[1] |
Sealing ring
|
|
| 68. |
955269
|
[2] |
Hexagon screw
|
L=12mm
|
| 69. |
941906
|
[2] |
Spring washer
|
|
| 70. |
952969
|
[1] |
Hose
|
L=50mm
|
| 71. |
943473
|
[2] |
Hose clamp
|
|
| 72. |
829714
|
[1] |
Sealing ring
|
|
| 72. |
418411
|
[11] |
Sealing ring
|
|
| 73. |
844624
|
[1] |
Pressure cap
|
(1542591)
|
| 74. |
958332
|
[1] |
V-belt
|
L=1550mm
|
| 76. |
840076
|
[1] |
Water pump
|
|
| 77. |
955998
|
[1] |
O-ring
|
|
| 78. |
807031
|
[1] |
Screw
|
See group 2A
|
| 80. |
955296
|
[2] |
Hexagon screw
|
|
| 81. |
941907
|
[2] |
Spring washer
|
|
| 82. |
833879
|
[2] |
Clamp
|
|
| 83. |
833414
|
[2] |
Air filter
|
|
| 84. |
833546
|
[2] |
Plug
|
|
| 85. |
833468
|
[1] |
Rubber hose
|
See group 2A
|
| 86. |
833998
|
[1] |
Exhaust pipe elbow
|
|
| 87. |
803374
|
[1] |
Gasket
|
|
| 88. |
807050
|
[1] |
Exhaust pipe flange
|
|
| 89. |
955319
|
[2] |
Hexagon screw
|
|
| 90. |
831733
|
[1] |
Strainer
|
See group 9
|
| 91. |
828242
|
[1] |
Coolant inlet
|
See group 9
|
