神钢零件查询(F4HFE613F E002) - ENGINE 5801398290 - 84359534 (1/12-) (10.102.01) - OIL SUMP & RELATED PARTS (504084707) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
972 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 2. | 4899019 | [32] | SCREW,Hex Flg, M8 x 1.25 x 35 | TOR |
| 3. | 4898301 | [1] | GASKET,0.42mm Thk | TOR |
| 5. | 4895291 | [3] | SCREW,Hex Flg, M10 x 1.5 x 20 | TOR |
| 6. | 2852238 | [1] | ELBOW | TOR Superseded by part number: 504064052 |
| 9. | 2852237 | [1] | SEALING RING | TOR Superseded by part number: 14457981 |
| 10. | 4894139 | [1] | PLUG,Hex Soc, M22 x 1.5 | TOR |
| 11. | 2853728 | [1] | O-RING,M23.47 ID x 2.62 Thk | TOR Superseded by part number: 14457780 |
| 12. | 4897330 | [1] | HEX SOCKET PLUG,M12 x 1.5 | TOR |
