神钢零件查询(F4HFE613F E002) - ENGINE 5801398290 - 84359534 (1/12-) (10.105.01) - PISTON - ENGINE (504336352) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
215 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84364065 | [6] | PISTON | TORStd. Superseded by part number: 8097879 |
| 1. | 84364066 | [6] | PISTON | TOR+0,4 Superseded by part number: |
| 1. | 84364067 | [6] | PISTON | TOR+0,8 Superseded by part number: |
| 2. | 4892712 | [6] | PISTON PIN,38mm OD x 82mm L | TOR |
| 3. | 2854030 | [12] | SNAP RING,M40.8 OD | TOR Superseded by part number: 504093651 |
| 4. | 2854603 | [6] | PISTON RING | BHB |
| 4. | 2856713 | [6] | PISTON RING | BHB0,4 Superseded by part number: |
| 4. | 2856714 | [6] | PISTON RING | BHB0,8 |
| 5. | 2830158 | [6] | PISTON RING,95.4mm ID x 104mm OD x 2.39mm Thk | TORStd. |
| 5. | 2830159 | [6] | PISTON RING,95.4mm ID x 104.4mm OD x 2.39mm Thk | BHB+0,4 |
| 5. | 2830160 | [6] | PISTON RING | BHB+0,8 |
| 6. | 2852037 | [6] | SEAL,95.3mm ID x 104mm OD x 4mm Thk | TOR Superseded by part number: 98486083 |
| 6. | 2853875 | [6] | OIL SCRAPER RING +0.,95.3mm ID x 104mm OD | BHB+0,4 |
| 6. | 2853876 | [6] | PISTON RING | BHB+0,8 |
