纽荷兰零件查询(FD20) - CRAWLER DOZER (L3.08/3[001]) - SEAT PANELS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
596 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10519221. | 89824840 | [30] | WASHER,4.3mm ID x 9mm OD x 0.8mm Thk | ZED |
| 13866050. | 13866050 | [15] | RIVET | LEC |
| 79023421. | 79023421 | [1] | GUARD | LECPROTECTION |
| 79023422. | 79023422 | [1] | BRAKE LINING | LECSEALING ELEMENT |
| 79023423. | 79023423 | [1] | BRAKE LINING | LECSEALING ELEMENT |
| 79023424. | 79023424 | [1] | BRAKE LINING | LECSEALING ELEMENT |
| 79023425. | 79023425 | [1] | BRAKE LINING | LECSEALING ELEMENT |
| 79023426. | 79023426 | [2] | BRAKE LINING | LECSEALING ELEMENT |
| 79029691. | 79029691 | [1] | PAD | LEC Superseded by part number: 4979701 |
| 79029701. | 79029701 | [1] | PAD | LEC Superseded by part number: 4979701 |
| 79029705. | 79029705 | [1] | PILLAR | LEC Superseded by part number: 79033718 |
| 79033718. | 79033718 | [1] | PILLAR | LEC |
| 79034969. | 79034969 | [1] | GUARD | LECPROTECTION |
| 79034970. | 79034970 | [1] | PANEL | LECSEALING ELEMENT |
| 79034975. | 79034975 | [1] | GASKET | LECSEALING ELEMENT |
| 79034976. | 79034976 | [1] | GASKET | LECSEALING ELEMENT |
| 79034977. | 79034977 | [1] | GASKET | LECSEALING ELEMENT |
| 79034978. | 79034978 | [1] | GASKET | LECSEALING ELEMENT |
