纽荷兰零件查询(FD20) - CRAWLER DOZER (B1.15[001]) - TRANSMISSION AND TORQUE CONVERTER VENT LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
166 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 592043. | 592043 | [1] | BANJO FITTING | LECFITTING |
| 592046. | 592046 | [1] | FILTER | LEC Superseded by part number: 86516755, 86516755, 9967002 |
| 4954923. | 4954923 | [1] | HYD CONNECTOR | LECFITTING |
| 10184417. | 10184417 | [2] | BANJO BOLT,M16 x 1.5 x 31mm | TTFUNION |
| 10257060. | 10257060 | [4] | SEALING WASHER,16.3mm ID x 22mm OD x 1.5mm Thk | BHBSEALING, M16.3 x 22 x 1.5, Copper Superseded by part number: 16508260 |
| 10291790. | 10291790 | [4] | COLLAR | MKTCLAMP Superseded by part number: 79084753 |
| 12605371. | 12605371 | [2] | LOCK WASHER,Int Tooth, M6 | MKTLOCKWASHER Superseded by part number: |
| 13276011. | 13276011 | [2] | SCREW,Pozidriv Pan Hd, M6 x 12mm, Cl 5.8 | LEC Superseded by part number: 86511828 |
| 19053382. | 19053382 | [1] | HOSE,10.00 mm | TTF Superseded by part number: 82849357 |
| 76014890. | 76014890 | [1] | HOSE | LEC Superseded by part number: 76015613 |
| 76015613. | 76015613 | [1] | FLEXIBLE HOSE | LECHOSE Superseded by part number: 76015720 |
| 76015720. | 76015720 | [1] | FLEXIBLE HOSE | LECHOSE Superseded by part number: 76020026 |
| 79009696. | 79009696 | [1] | HYD CONNECTOR | LECUNION Superseded by part number: 76003142 |
| 79062072. | 79062072 | [1] | FITTING | LECUNION |
| 79083842. | 79083842 | [4] | HOSE CLAMP,M16-27 | LECCLAMP, HOSE, M16-27 Superseded by part number: 18088392 |
