纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.04/1A[003]) - TRANSMISSION CLUTCHES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
934 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 14468681. | 14468681 | [1] | O-RING,0.139" Thk x 8.484" ID, -268, Cl 7, 75 Duro | LEC-268, Cl 7, 8.484" ID x .139" Thk |
| 79019030. | 79019030 | [8] | PLATE | LECDISK Superseded by part number: 79035350 |
| 79030937. | 79030937 | [1] | GEAR | LEC |
| 79030938. | 79030938 | [1] | SLEEVE | LEC |
| 79030950. | 79030950 | [8] | SPRING | LEC Superseded by part number: 79059106 |
| 79030951. | 79030951 | [8] | DISC | LECDISK |
| 79030967. | 79030967 | [1] | DISC | LECDISK |
| 79030969. | 79030969 | [1] | RING | LECRETAINING RING |
| 79031687. | 79031687 | [3] | SEAL,84mm ID x 92mm OD x 3mm Thk | LECSECTOR |
| 79040340. | 79040340 | [1] | RING,82mm ID x 90mm OD x 2.38mm Thk | LECO-RING |
| 79040451. | 79040451 | [1] | DRUM | LEC Superseded by part number: 79055329 |
| 79040481. | 79040481 | [1] | PISTON | LEC Superseded by part number: 79062752, 79062732 |
| 79045810. | 79045810 | [1] | KIT | LEC-CONSISTING OF |
| 79050979. | 79050979 | [1] | SPRING | LEC |
| 79055329. | 79055329 | [1] | DRUM | LEC |
| 79062732. | 79062732 | [1] | RING,217.8mm ID x 224mm OD x 6mm Thk | LEC |
| 79062752. | 79062752 | [1] | PISTON | LEC |
