纽荷兰零件查询(FD20) - CRAWLER DOZER (B2.30[002]) - TRANSMISSION HYDRAULIC CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
615 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10165240. | 10165240 | [1] | SEALING RING | MKTSLEEVE |
| 10296160. | 10296160 | [1] | SEALING WASHER,M12.2 x 18 x 1, Copper | MKTGASKET Superseded by part number: 4858607 |
| 10516871. | 10516871 | [1] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10979231. | 10979231 | [1] | BOLT,Hex, M10 x 16mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87547661 |
| 11902417. | 11902417 | [1] | NUT | MKT |
| 11913717. | 11903717 | [1] | HYD CONNECTOR,M8 x 1.25 x 16mm | BASUNION Superseded by part number: 11903714 |
| 14330260. | 2852057 | [2] | SEALING WASHER,M8 x 12 x 1 Thk | TOR(Gasket) M8 x 12 x 1 Thk |
| 76002385. | 76002385 | [1] | SUPPORT | LEC Superseded by part number: 79020207 |
| 79004922. | 79004922 | [1] | RIGID TUBE | LECHOSE Superseded by part number: 79009661 |
| 79012600. | 79012600 | [1] | PRESSURE SWITCH | LECSWITCH Superseded by part number: 84182607 |
| 79015581. | 79015581 | [1] | SWITCH | LEC Superseded by part number: 79012600 |
| 79020207. | 79020207 | [1] | SUPPORT | LEC |
| 79022773. | 79022773 | [1] | GAUGE | LECOIL PRESSURE GAUGE Superseded by part number: 79051195 |
| 79024783. | 79024783 | [1] | RIGID TUBE | LECPIPE |
