凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-03) - HITCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
991 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
668406R91
|
[1] |
|
P
PIN ASSY, hitch
|
| . . |
517843R1
|
[2] |
COTTER PIN
|
IH
PIN, 3/16 quick attachable cot. Superseded by part number: 86000109
|
| 2. |
662145R1
|
[1] |
STRAP
|
IH
hitch clevis lower
|
| . . |
271563
|
[2] |
SUPPORT,Hex, 5/8" - 11 x 2 1/4", Gr 5
|
NNA
SCREW, 5/8-11 x 2-1/4 hex-hd cap Superseded by part number: 413-1036, 413-1036, NLS
|
| . . |
667927R1
|
[2] |
LOCK NUT,5/8"-11, GB
|
IH
NUT, 5/8-11 hex. lock Superseded by part number: 231-42110
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 3. |
670404R1
|
[1] |
HOLDER
|
IH
STRAP, hammer hitch
|
| . . |
17448R1
|
[2] |
BOLT (SPREADER)
|
IH
BOLT, 1/2 x 1-1/4 hex-hd mach Superseded by part number: 271559
|
| . . |
102637
|
[2] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 4. |
670405R1
|
[1] |
|
P
LOCK, hitch channel
|
| . . |
13419R1
|
[1] |
|
P
BOLT, 3/4 x 3 sq-hd mach
|
| . . |
18444R1
|
[1] |
NUT,3/4"-10, GB
|
IH
3/4-10 ESNA stop Superseded by part number: 22244R1
|
| 5. |
670403R1
|
[1] |
|
P
STRAP, hitch pivot
|
| . . |
271562
|
[2] |
SHIELD,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
SCREW, 5/8-11 x 2 hex-hd cap Superseded by part number: 413-1032, 413-1032, NLS
|
| . . |
102639
|
[2] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
413-1252
|
[1] |
BOLT,Hex, 3/4" - 10 x 3-1/4", Gr 5
|
CAS
SCREW, 3/4-10 x 3-1/4 hex-hd mach Superseded by part number: 88747
|
| 6. |
670400R92
|
[1] |
|
P
HITCH ASSY, channel
|
| 7. |
662144R1
|
[1] |
STRAP
|
IH
hitch clevis upper
|
