纽荷兰零件查询(FD20) - CRAWLER DOZER (B4.08[002]) - REAR DRIVE BODY EASINGS AND COVERS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
297 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 76002727. | 76002727 | [6] | SCREW | LEC |
| 76002728. | 76002728 | [4] | STUD | LEC |
| 79003074. | 79003074 | [4] | SCREW | LEC Superseded by part number: 16163031 |
| 79003076. | 79003076 | [6] | NUT | LEC Superseded by part number: 12166721 |
| 79010782. | 79010782 | [10] | WASHER | LEC |
| 79018103. | 79018103 | [1] | WEIGHT | LECBALLAST |
| 79018851. | 79018851 | [2] | STUD | LECSCREW |
| 79026174. | 79026174 | [4] | STUD | LEC |
| 79027310. | 79027310 | [1] | WEIGHT | LECBALLAST |
