纽荷兰零件查询(FD20) - CRAWLER DOZER (A1.02[002]) - OIL SUMP AND CRANKCASE COVERS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
307 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 539705. | 539705 | [1] | COVER | LEC Superseded by part number: 98450843 |
| 539706. | 539706 | [1] | GASKET | MKT Superseded by part number: 98438825 |
| 4530113. | 4530113 | [1] | COVER | PA |
| 4530123. | 4530123 | [1] | SEAL | BRE Superseded by part number: 4863958 |
| 4734727. | 4734727 | [1] | SUPPORT | LEC Superseded by part number: 4734726 |
| 4741913. | 4741913 | [1] | SUPPORT | LEC Superseded by part number: 98464798, 98475327 |
| 4750615. | 4750615 | [1] | SUPPORT | LEC Superseded by part number: 4741913, 40000740 |
| 4750616. | 4750616 | [2] | DOWEL | LEC |
| 10801630. | 10801630 | [1O] | WASHER | ZED Superseded by part number: 4837398 |
| 10837810. | 10837810 | [2] | DOWEL,M12 x 30.00mm | PA |
| 10902221. | 10902221 | [7] | BOLT,Hex, M6 x 16mm, CL 8.8 | BHBBOLT, Hex, M6 x 16, 8.8 Superseded by part number: |
| 10902721. | 10902721 | [1] | SCREW,Hex, M6 x 28mm, Cl 8.8, Full Thd | MKT Superseded by part number: 86977786 |
| 11197779. | 11197779 | [8] | BELLEVILLE WASHER,6.40mm ID x 12.00mm OD x 1.20mm, 1.63mm, Cl 8.8, ZNM | TTFLOCKWASHER Superseded by part number: 17088474 |
| 11198379. | 11198379 | [2] | SPRING WASHER,10.5mm ID x 20mm OD x 2.6mm Thk | TTFLOCKWASHER Superseded by part number: 11198374 |
| 12164711. | 12164711 | [2] | NUT,M10 x 1.25, Cl 8 | TTF Superseded by part number: 12164714 |
| 13449321. | 13449321 | [2] | STUD | MKT Superseded by part number: 13449320 |
| 13449330. | 13449330 | [2] | STUD | PA |
| 13516521. | 13516521 | [1] | STUD | LEC |
| 14476582. | 14476582 | [1] | GASKET | LECO-RING Superseded by part number: 98464798 |
| 15540730. | 15540730 | [10] | SCREW | MKT Superseded by part number: 15540734 |
| 79037444. | 79037444 | [1] | KIT | LEC Superseded by part number: 75127431 |
