现代零件查询R210LC-7A BOOM MOUNTING (LONG REACH)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
856 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
61N6-11011BG
|
[1] |
PIN ASSY
|
|
| 2. |
61EM-00111
|
[1] |
PIN
|
|
| 3. |
61N6-00171
|
[1] |
PIN ASSY
|
|
| 4. |
61N8-01601BG
|
[2] |
PIN ASSY
|
|
| 5. |
61N8-01641
|
[2] |
PIN ASSY
|
|
| 6. |
61N8-01301
|
[1] |
PIN ASSY
|
|
| 7. |
61N6-11061
|
[2] |
PIN ASSY
|
|
| 8. |
62E1-1107-DA
|
[1] |
WASHER-HARDENED
|
|
| 9. |
62E1-1108-DA
|
[1] |
NUT-SLOTTED
|
|
| 11. |
61N8-00160
|
[4] |
SPACER-PIN
|
|
| 11. |
61Q8-00140
|
[4] |
SPACER-PIN
|
|
| 12. |
61N6-11200
|
[1] |
BRACKET WA
|
|
| 13. |
61N8-00130
|
[1] |
SPACER-PIN
|
|
| 13. |
61Q8-00120
|
[1] |
SPACER-PIN
|
|
| 14. |
S461-800902
|
[1] |
PIN-SPLIT
|
|
| 15. |
61N8-13020BG
|
[1] |
PLATE
|
|
| 16. |
S501-200002
|
[2] |
PIN-SELF LOCKING
|
|
| 18. |
S017-16040D
|
[2] |
BOLT-HEX
|
|
| 19. |
S017-160506
|
[6] |
BOLT-HEX
|
|
| 21. |
S017-16025D
|
[5] |
BOLT-HEX
|
|
| 23. |
S411-160006
|
[8] |
WASHER-SPRING
|
|
| 24. |
61N8-00310-DA
|
[5] |
WASHER-HARDENED
|
|
| 25. |
S391-065120
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 27. |
S391-080140
|
[5] |
SHIM-ROUND(1.0T)
|
|
| 31. |
61N6-11000
|
[1] |
STAY WA
|
|
| 33. |
61N8-19020
|
[2] |
STOPPER-PIN
|
|
| 34. |
S017-161606
|
[2] |
BOLT-HEX
|
|
| 35. |
S205-16100B
|
[4] |
NUT-HEX
|
|
| 38. |
S390-080140A
|
[1] |
SHIM-ROUND(0.5T)
|
|
| 39. |
S390-090190A
|
[1] |
SHIM-ROUND(0.5T)
|
|
