神钢零件查询(F4HFE613G B004) - ENGINE 5801862194 - 47587184 TIER4 B (9/15-) (10.218.AI[01]) - INJECTION PIPE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
414 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854549 | [3] | INJECTION PIPE | TORAssy, Incl 2, 3 Superseded by part number: |
| 2. | NSS | [3] | NOT SOLD SEPARAT | CONPipe, Incl. In 1 |
| 3. | 2854548 | [2] | SILENTBLOC | TOR |
| 4. | 2854544 | [3] | INJECTION PIPE | TORAssy, Incl 3, 5 Superseded by part number: |
| 5. | NSS | [3] | NOT SOLD SEPARAT | CONTube, Incl. In 4 |
| 6. | 2854552 | [1] | INJECTION PIPE | TORAssy, Incl 6 - 11 Superseded by part number: |
| 7. | 2854556 | [2] | CLAMP BRACKET | TOR |
| 7. | 2854558 | [2] | RUBBER SEAL | TOR |
| 8. | 2854557 | [2] | CLAMP BRACKET | TOR |
| 8. | 2854555 | [1] | CLAMP BRACKET | TOR |
| 8. | 2855127 | [1] | CLAMP BRACKET | TOR |
| 9. | 2854559 | [2] | SCREW | TOR Superseded by part number: |
| 11. | 4899020 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 11. | 4896884 | [1] | BOLT,Flng, M8 x 1.25 x 16mm, Cl 10.9 | TOR |
| 12. | 2853537 | [4] | BOLT,Hex Flange Head Cap M8 x 1.25 x 125mm | TOR Superseded by part number: 504053874 |
| 13. | 2852434 | [1] | SPACER | TOR Superseded by part number: 13605711 |
