纽荷兰零件查询(FD20) - CRAWLER DOZER (A1.06[001]) - CAMSHAFT DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
731 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4526173. | 4526173 | [1] | BUSHING | MKTBUSH Superseded by part number: 4560955 |
| 4560955. | 4560955 | [1] | BUSHING | BREBUSH |
| 4606319. | 4606319 | [2] | KEY | ZED |
| 4609098. | 4609098 | [1] | GEAR | BREDRIVING GEAR |
| 4619882. | 4619882 | [1] | GEAR | BREDRIVEN GEAR |
| 4619885. | 4619885 | [1] | DOWEL | ZED |
| 4630549. | 4630549 | [1] | DRIVEN GEAR | BRE |
| 4649835. | 4649835 | [1] | PIN | BRE |
| 4668208. | 4668208 | [1] | BUSHING | LECBUSH Superseded by part number: 4526173 |
| 4670139. | 4670139 | [2] | RING | BRE |
| 4672985. | 4672985 | [1] | FLANGE | BRE |
| 4672986. | 4672986 | [3] | SCREW | BRE |
| 14233630. | 14233630 | [6] | SCREW,M10 x 1.25 x 30mm | MKT Superseded by part number: 16323531 |
