神钢零件查询(F4HFE613G B004) - ENGINE 5801862194 - 47587184 TIER4 B (9/15-) (10.400.AE[01]) - COOLANT HEATING LINES Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
888 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899091 | [3] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 2. | 2853131 | [1] | HOUSING | TOR Superseded by part number: 504079269 |
| 3. | 2853445 | [1] | BRACKET | TOR Superseded by part number: 504079607 |
| 4. | 2853133 | [1] | GASKET,51.5mm ID x 61.5mm OD x 16.5mm Thk | TOR Superseded by part number: 504078856 |
| 5. | 4895131 | [1] | HOUSING | TOR Superseded by part number: |
| 6. | 4899110 | [3] | SCREW,Hex Flg, M6 x 1 x 20 | TOR |
| 9. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 9. | 2854866 | [1] | HEX SOCKET PLUG,3/4"-14 NPTF | TOR Superseded by part number: 4893036 |
