现代零件查询R210LC-7A BUCKET(1.05M3 SAE HEAPED, CAST, #0681-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
1001 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
67N6-32000
|
[1] |
BUCKET ASSY-CASTING
|
|
| . |
67N6-32001
|
[1] |
BUCKET ASSY-CASTING
|
|
| 1. |
67N6-32010
|
[1] |
BUCKET WA-CASTING
|
|
| 1. |
67N6-32011
|
[1] |
BUCKET WA-CASTING
|
|
| 1-1. |
67N6-31320
|
[5] |
ADAPTER-TOOTH
|
|
| 2. |
61Q6-31310
|
[5] |
POINT-TOOTH
|
|
| 3. |
E161-3035
|
[5] |
PIN-TOOTH
|
|
| 4. |
61E5-11150
|
[5] |
WASHER-LOCK
|
|
| 5. |
67N6-31040
|
[1] |
SIDE REINF-LH
|
|
| 5. |
67N6-31041
|
[1] |
SIDE REINF-LH
|
|
| 5. |
67N6-31140
|
[1] |
SIDE REINF-LH
|
|
| 6. |
67N6-31050
|
[1] |
SIDE REINF-RH
|
|
| 6. |
67N6-31051
|
[1] |
SIDE REINF-RH
|
|
| 6. |
67N6-31150
|
[1] |
SIDE REINF-RH
|
|
| 7. |
S019-16060D
|
[6] |
BOLT-HEX
|
|
| 8. |
S205-16100B
|
[6] |
NUT-HEX
|
|
| 9. |
S411-160006
|
[6] |
WASHER-SPRING
|
|
