凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-36) - PLUNGER CRANK SHIELD ATTACHMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
218 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
671983R91
|
[1] |
SHIELD
|
IH
ASSY, plunger crank
|
| 2. |
667736R1
|
[2] |
HINGE
|
IH
tool box door
|
| . . |
443547
|
[4] |
|
P
SCREW, 10-12 x 1/2 znd slt-hd tap
|
| 3. |
354746R1
|
[1] |
SPRING
|
IH
plunger crank shield
|
| . . |
469668R1
|
[1] |
WASHER
|
IH
13/32 x 3/4 x 16 ga C-Z Superseded by part number: 86632580
|
| . . |
472144R1
|
[1] |
NUT
|
IH
3/8-16 znd hex. lock Superseded by part number: 385525R1
|
| 4. |
671987R1
|
[1] |
PAWL
|
IH
plunger crank shield latch
|
| 5. |
671988R1
|
[1] |
SUPPORT
|
IH
SHEET, plunger crank shield rear
|
| . . |
18764R1
|
[2] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 znd hex-hd mach Superseded by part number: 424-512
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 6. |
668035R11
|
[1] |
LATCH
|
IH
ASSY, plunger crank shield
|
| . . |
18422R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 2
|
IH
BOLT, 3/8 x 1-3/4 znd sq-nk crg Superseded by part number: 411-628
|
