沃尔沃零件查询MD11; MD11C; MD11D; MD17; MD17C; MD17DMiscellaneous EquipmentRebuilding Kit for Fresh-water CoolingEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
553 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
829962
|
[1] |
Mounting kit
|
|
| 2. |
840088
|
[1] |
Pulley
|
|
| 3. |
829900
|
[1] |
Bracket
|
|
| 4. |
829948
|
[1] |
Tensioner
|
|
| 5. |
955328
|
[1] |
Hexagon screw
|
L=80mm
|
| 6. |
963107
|
[1] |
Lock nut
|
|
| 7. |
941908
|
[2] |
Spring washer
|
|
| 8. |
845589
|
[1] |
Spacer sleeve
|
|
| 9. |
940142
|
[2] |
Hexagon screw
|
L=30mm
|
| 10. |
941907
|
[2] |
Spring washer
|
|
| 11. |
191172
|
[2] |
Washer
|
|
| 12. |
955319
|
[1] |
Hexagon screw
|
L=35mm
|
| 13. |
941908
|
[1] |
Spring washer
|
|
| 14. |
955295
|
[1] |
Hexagon screw
|
L=20mm
|
| 15. |
191172
|
[1] |
Washer
|
|
| 16. |
941907
|
[1] |
Spring washer
|
|
| 17. |
955782
|
[1] |
Hexagon nut
|
|
| 18. |
940132
|
[1] |
Hexagon screw
|
L=35mm
|
| 19. |
941907
|
[1] |
Spring washer
|
|
| 20. |
807120
|
[1] |
Tube
|
Must be pressed into the exhaust manifold.
|
| 21. |
840536
|
[1] |
Oil dipstick
|
|
| 22. |
949187
|
[1] |
O-ring
|
(955972)
|
| 23. |
829984
|
[1] |
Cover
|
|
| 24. |
807363
|
[1] |
Sealing ring
|
|
