纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.23/1[001]) - AIR CLEANER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
845 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8322477. | 8322477 | [2] | WASHER | MODSEAL |
| 8322503. | 8322503 | [1] | HYDRAULIC VALVE | LECVALVE |
| 8322505. | 8322505 | [2] | NUT | LEC |
| 8322542. | 8322542 | [1] | BODY | LECCOVER Superseded by part number: REFERENCE |
| 8322543. | 8322543 | [1] | BOWL | LEC Superseded by part number: 70662618 |
| 8322546. | 8322546 | [1] | AIR FILTER | LECFILTERING ELEMENT Superseded by part number: 70684734 |
| 8322547. | 8322547 | [1] | AIR FILTER | LECFILTERING ELEMENT Superseded by part number: 70662477 |
| 8322548. | 8322548 | [1] | CLAMP | LEC Superseded by part number: REFERENCE |
| 8322551. | 8322551 | [1] | GASKET | LECO-RING Superseded by part number: REFERENCE |
| 10101101. | 10101101 | [1] | NUT | BHB |
| 12643701. | 12643701 | [1] | WASHER,6.15mm ID x 18mm OD x 1.5mm Thk | LEC Superseded by part number: 12643704 |
| 79043780. | 79043780 | [1] | AIR FILTER | LECFILTERING ELEMENT Superseded by part number: 1930747 |
| 79043781. | 79043781 | [1] | AIR FILTER | LECFILTERING ELEMENT Superseded by part number: 70662477 |
