凯斯零件查询(37) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/63-12/88) (B-10) - MAIN FRAME Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
560 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662988R95
|
[1] |
|
P
AXLE
|
| . . |
17427R1
|
[2] |
BOLT, mach, 7/16 x 1
|
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
7/16
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 2. |
662358R94
|
[1] |
|
P
BRACE, diagonal
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, cge, 3/8 x 1
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 3. |
662148R1
|
[1] |
GUSSET
|
IH
axle R.
|
| 4. |
665582R1
|
[1] |
|
P
STRAP, diagonal brace stiffener, 37 Baler 501G thru 7454 K, 47 Baler 501G thru 8820 K
|
| . . |
17426R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 mach Superseded by part number: 24840R1
|
| 5. |
671627R91
|
[1] |
|
P
TIE ASSY, main frame, 37 Baler 7455L up, 47 Baler 8821L up
|
| . . |
17446R1
|
[2] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 hex-hd mach Superseded by part number: 88011
|
| 6. |
671725R91
|
[1] |
SUPPORT ASSY, bale chamber, 37 Baler 7455L up, 47 Baler 8821L up
|
|
| . . |
220081
|
[2] |
SEALING ELEMENT
|
NNA
3/4-10 hex. Superseded by part number: 425-1012, 425-1012, 84814913
|
