纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.27[001]) - INJECTION PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
930 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 774044. | 774044 | [12] | SCREW | BRE Superseded by part number: 79062792 |
| 10516471. | 10516471 | [3] | LOCK WASHER | BHBWASHER Superseded by part number: 86517328 |
| 10516871. | 10516871 | [12] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFI Superseded by part number: 10571873 |
| 12606871. | 12606871 | [2] | WASHER | LEC Superseded by part number: 12606879 |
| 79023665. | 79023665 | [3] | NUT | LEC Superseded by part number: 15896221 |
| 79026503. | 79026503 | [2] | SCREW | HIT Superseded by part number: 79032313 |
| 79031247. | 15896421 | [12] | NUT,M5, Cl 10 | TTF Superseded by part number: 1112803 |
| 79032312. | 79032312 | [6] | PLUG | LEC Superseded by part number: 772334 |
| 79038377. | 79038377 | [1] | BODY | LEC |
| 79038379. | 79038379 | [1] | COVER | LEC Superseded by part number: 772219 |
| 79038380. | 79038380 | [12] | WASHER | LEC Superseded by part number: 773325 |
| 79038381. | 79038381 | [6] | SEAL | LECLINING |
| 79038465. | 79038465 | [3] | STUD | LEC Superseded by part number: 11500211 |
| 79038466. | 79038466 | [1] | SEAL | LECLINING |
| 79038467. | 79038467 | [1] | GASKET | LECLINING Superseded by part number: 772223 |
| 79038468. | 79038468 | [1] | COVER | LEC Superseded by part number: 772221 |
| 79038470. | 79038470 | [1] | PLUG | LEC Superseded by part number: 772292 |
| 79038471. | 79038471 | [1] | SEAL | LECLINING Superseded by part number: 772060 |
| 79038473. | 79038473 | [1] | PRESSURE RELIEF VALVE | LECVALVE Superseded by part number: 772314 |
| 79038475. | 79038475 | [1] | SPRING | LEC |
| 79038716. | 79038716 | [1] | BUSHING | LEC |
| 79050751. | 79050751 | [12] | STUD | LEC Superseded by part number: 79026505 |
| 79050754. | 79050754 | [1] | BALL | LEC |
| 79050755. | 79050755 | [1] | PLUG | LEC |
| 79050760. | 79050760 | [1] | KIT | LECSET Superseded by part number: 1308047 |
| 79106751. | 76026115 | [1] | SEAL | LECLINING |
