| 1. |
667788R1
|
[1] |
|
P
SPACER, trip arm, for twine Baler
|
| 2. |
662279R94
|
[1] |
MOUNTING ROD
|
IH
ROD, trip, cpt., for twine Balers, for service replacement of 662279R93 also order 670669R1, collar
|
| 2. |
664779R93
|
[1] |
|
P
ROD, trip, cpt., for wire Balers, for service replacement of 664779R92 also order 670669R1, collar
|
| . . |
19269R1
|
[1] |
LOCK PIN,3/8" x 1", Slotted
|
IH
PIN, 3/8" x 1", Slotted Superseded by part number: 138-170
|
| 3. |
667782R1
|
[2] |
SHEAVE
|
IH
trip rod Superseded by part number: 210557C1
|
| . . |
17845R1
|
[1] |
BOLT, 5/8-11 x 5-1/2 hex-hd mach
|
|
| . . |
102639
|
[1] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
103325
|
[1] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 4. |
670669R1
|
[1] |
COLLAR
|
IH
trip set, used with 1 in. trip rods Superseded by part number: 667502R91
|
| 4. |
666748R2
|
[1] |
|
P
COLLAR, trip set, used with 3/4 in. trip rods
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
|
| . . |
Q1597
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga. Superseded by part number: 86632580
|
| . . |
103321
|
[1] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
102635
|
[1] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| 5. |
667781R1
|
[1] |
ROLLER
|
IH
trip rod
|
| 6. |
667778R1
|
[2] |
BUSHING
|
IH
trip sheave brg, 37-501G thru 4893H, 47-501G thru 4164H
|
| 8. |
667450R92
|
[1] |
|
P
SUPPORT W/BUSHINGS, trip sheave brg 37-501G thru 4893H, 47-501G thru 4164H
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, 3/8 x 1 crg
|
| . . |
17500R1
|
[1] |
BOLT,Hex, 5/8"-11 x 1 3/4", G2
|
IH
5/8 x 1-3/4 hex-hd mach Superseded by part number: 24-1028
|
| . . |
Q1505
|
[2] |
WASHER
|
IH
13/32 x 1 x 16 ga Superseded by part number: 495-21044
|
| 9. |
667452R91
|
[1] |
|
P
WHEEL, meter 37-501G thru 4893H, 47-501G thru 4164H
|
| . . |
551659R1
|
[4] |
WASHER
|
IH
29/32 x 1-1/2 x 22 ga
|
| 10. |
668082R1
|
[1] |
ANCHOR
|
IH
spring trip
|
| . . |
15039R1
|
[1] |
BOLT
|
IH
3/8 x 1-1/2 crg Superseded by part number: 18685R1
|
| . . |
15581R1
|
[1] |
BOLT,3/8"-16 x 1 1/2", G2
|
IH
3/8 x 1-1/2 plow Superseded by part number: 19021R1, 118-141
|
| 11. |
6646
|
[1] |
SPRING
|
IH
trip rod Superseded by part number: 204009C1
|
| 12. |
662072R1
|
[1] |
NO LONGER SERVICED
|
IH
STUD, trip arm, for twine Baler Superseded by part number: 662072R2
|
| 12. |
664778R1
|
[1] |
PIN
|
IH
STUD, trip arm, for wire Baler
|
| . . |
Q3501
|
[2] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga. (or as req.) Superseded by part number: 95-81056
|
| . . |
103386
|
[1] |
COTTER PIN,1/8" x 1 1/4"
|
IH
Pin, Split (Cotter), 1/8" x 1 1/4" Superseded by part number: 87395
|
| 13. |
662020R1
|
[1] |
STUD
|
IH
trip arm roller
|
| . . |
103373
|
[1] |
COTTER PIN,3/32" x 3/4"
|
IH
Pin, Split (Cotter), 3/32" x 3/4" Superseded by part number: 32-612
|
| . . |
28035K
|
[1] |
WASHER
|
IH
13/32 x 1 x 22 ga. Superseded by part number: 495-81136
|
| 14. |
662019R1
|
[1] |
ROLLER,28.57mm OD x 12.7mm L
|
IH
trip arm
|
| 16. |
663163R21
|
[1] |
ARM
|
IH
trip, for wire Baler
|
| . . |
17053R1
|
[1] |
LOCK PIN,Sl Spring, 1/4" x 1 3/8"
|
IH
PIN, 1/4" x 1 3/8", Slotted Superseded by part number: 87524
|
| 17. |
70733H
|
[1] |
SPRING
|
IH
trip, for wire Baler
|
| 17. |
101330H
|
[1] |
SPRING
|
IH
trip, for twine Baler
|
| 18. |
668329R1
|
[1] |
|
P
ANCHOR, spring trip, for wire Baler
|
| . . |
17426R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 hex-hd mach, for twine Balers Superseded by part number: 24840R1
|
| . . |
15563R1
|
[1] |
BOLT,3/8"-16 x 1 1/4", G2, Full Thd
|
IH
PLOW, (#3) For twine balers 3/8"-16 x 1 1/4", G2, Full Thd Superseded by part number: 19031R1
|
| 21. |
662018R11
|
[1] |
LEVER
|
IH
ARM, trip, for twine Baler
|
| 22. |
668999R1
|
[2] |
BUSHING
|
IH
meter wheel flanged, 37-4894H up, 47-4165H up
|
| 23. |
669000R1
|
[1] |
|
P
TUBE, meter wheel shaft 37-4894H up, 47-4165H up
|
| 24. |
669001R1
|
[1] |
|
P
WHEEL, bale length control 37-4894 up, 47-4165H up
|
| 25. |
668998R1
|
[1] |
|
P
BRACKET, meter wheel shaft brg, 37-4894H thru 9052L, 47-4165H thru 12029L, for service replacement of 668998R1 order 670665R1 bracket and 670670R1 spacer, also 2 each 15023R1 bolt, 102635 nut, 103321 washer
|
| 25. |
670665R1
|
[1] |
|
P
BRACKET, meter wheel shaft brg, 37-9053L, up, 4712030L, up
|
| 26. |
670670R1
|
[2] |
|
P
SPACER, meter wheel bracket, 379053L up, 4712030L up
|
| . . |
86508749
|
[2] |
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5
|
GI
BOLT, cge. 3/8 x 1-1/4
|
