神钢零件查询(F4HFE613H B003) - ENGINE 5801731919 - 47519637 (2/14-) (10.105.AB) - CONNECTING ROD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING; Incl in 1 |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONRod, Incl in 1 |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONCap, Incl in 1 |
| 6. | 47597619 | [6] | BEARING ASSY,88.5-90mm Free Spread, 2.464mm W | BN |
| 6. | 47597197 | [6] | BEARING ASSY,74.5-75.5mm Free Spread, 1.958mm W | BN |
| 6. | 47597199 | [6] | BEARING ASSY,74.5-75.5mm Free Spread, 1.958mm W | BN |
