凯斯零件查询(37) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/63-12/88) (B-60[A]) - PLUNGER CRANK SHIELD ATTACHMENT, FOR ENGINE DRIVE ONLY WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
395 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
667974R1
|
[1] |
|
P
SHIELD, plunger crank front
|
| . . |
18764R1
|
[4] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 znd hex-hd mach Superseded by part number: 424-512
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 2. |
667972R91
|
[1] |
|
P
SHIELD, plunger crank cpt
|
| . . |
619855R1
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga cd-pltd Superseded by part number: 86637953
|
| . . |
667804R1
|
[1] |
|
P
SUPPORT, plunger crank shield
|
| . . |
2751049R1
|
[1] |
PRODUCT GRAPHIC
|
IH
International McCormick, on both sides of plunger crank shield Superseded by part number: 547495R92
|
