纽荷兰零件查询(FD20) - CRAWLER DOZER (A3.02/1[001]) - OIL SCAVENGE PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
142 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4555591. | 4555591 | [2] | BRONZE BUSHING | BREBUSHING |
| 4555595. | 4555595 | [2] | BUSHING | ZED |
| 4562749. | 4562749 | [2] | BUSHING | LEC Superseded by part number: 4555595 |
| 4665206. | 4665206 | [1] | DRIVING GEAR | BREDRIVEN GEAR |
| 4665207. | 4665207 | [1] | BODY | BRE |
| 4668264. | 4668264 | [2] | BUSHING | LEC Superseded by part number: 4562749 |
| 4974299. | 4974299 | [1] | COVER | LEC |
| 4980774. | 4980774 | [1] | COVER | LEC |
| 4981267. | 4981267 | [1] | GEAR | LECDRIVEN GEAR |
| 10837610. | 10837610 | [4] | DOWEL | MKT Superseded by part number: |
| 10839610. | 10839610 | [2] | DOWEL,M8 x 12mm | TOR |
| 14239530. | 14239530 | [4] | SCREW | MKT Superseded by part number: 16322130 |
