纽荷兰零件查询(FD20) - CRAWLER DOZER (A4.01[001]) - RADIATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
698 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4959324. | 4959324 | [1] | INTRODUCTION CAP | MODCAP Superseded by part number: 76027863 |
| 4974337. | 4974337 | [8] | PAD | LEC Superseded by part number: 76069292 |
| 4974343. | 4974343 | [4] | WASHER | LEC Superseded by part number: 79111680 |
| 4977099. | 4977099 | [1] | WASHER | LEC Superseded by part number: 75223895 |
| 10516671. | 10516671 | [8] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10517071. | 10517071 | [8] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 11112631. | 11112631 | [4] | BOLT,Hex, M12 x 35mm, Cl 10.9 | LECBOLT, Hex, M12 x 35, 10.9 Superseded by part number: 626-12035 |
| 11113931. | 11113931 | [2] | SCREW,Hex, M12 x 85mm, Cl 10.9 | LEC Superseded by part number: 86979023 |
| 11114031. | 11114031 | [2] | BOLT,Hex, M12 x 90, 10.9 | LEC Superseded by part number: 412605 |
| 11702921. | 11702921 | [2] | NUT,M12, Cl 10 | LEC Superseded by part number: 17038425 |
| 12644401. | 12644401 | [20] | WASHER,6.15mm ID x 15mm OD x 1mm Thk | TTF Superseded by part number: 12644404 |
| 12646721. | 12646704 | [8] | WASHER,8.15mm ID x 20mm OD x 2mm Thk | LEC |
| 12646921. | 12646921 | [2] | WASHER,12.2mm ID x 28mm OD x 3mm Thk | BHB Superseded by part number: 16887624 |
| 13868350. | 13868350 | [20] | RIVET | MKT |
| 16043431. | 16043431 | [4] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 79008618. | 79008618 | [2] | GASKET | LECSEALING STRIP |
| 79010957. | 79010957 | [2] | BRAKE LINING | LECSEALING STRIP |
| 79015928. | 79015928 | [1] | RADIATOR | LEC |
| 79016737. | 79016737 | [2] | BRACKET | LEC |
| 79016738. | 79016738 | [4] | SPACER | LEC Superseded by part number: 79111681 |
| 79017338. | 79017338 | [1] | GUARD | LECSEALING STRIP |
| 79017340. | 79017340 | [1] | GUARD | LECSEALING STRIP |
| 79021821. | 79021821 | [1] | RADIATOR | LEC |
| 79027735. | 79027735 | [1] | BRAKE LINING | LECSEALING STRIP |
| 79027736. | 79027736 | [1] | BRAKE LINING | LECSEALING STRIP |
