纽荷兰零件查询(FD20) - CRAWLER DOZER (A4.01[002]) - RADIATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
706 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10450190. | 10450190 | [2] | CLAMP,10mm, Coat, 9mm Bolt Hole, P Type | JESBRACKET Superseded by part number: |
| 10516671. | 10516671 | [23] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 12646721. | 12646704 | [23] | WASHER,8.15mm ID x 20mm OD x 2mm Thk | LEC |
| 16043231. | 16043231 | [1] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LECSCREW |
| 16043431. | 16043431 | [10] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 16043631. | 16043631 | [12] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHBBOLT, Hex, M8 x 25, 10.9 Superseded by part number: 43234 |
| 79017341. | 79017341 | [1] | CONVEYOR | LEC |
| 79017346. | 79017346 | [1] | GRILLE | LECRADIATOR GRILLE |
| 79017350. | 79017350 | [1] | GRILLE | LEC |
| 79017373. | 79017373 | [1] | GRILLE | LEC |
| 79025742. | 79025742 | [1] | GRILLE | LEC |
| 79027738. | 79027738 | [1] | CONVEYOR | LEC |
