纽荷兰零件查询(FD20) - CRAWLER DOZER (A4.09[002]) - FAN AND FAN DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
762 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4629138. | 4629138 | [1] | CLIP | LECSNAP FASTENER Superseded by part number: |
| 4629139. | 4629139 | [1] | WASHER | LEC |
| 4734807. | 4734807 | [1] | BEARING ASSY | LECBEARING Superseded by part number: 4756160 |
| 4735974. | 4735974 | [1] | ARM | LEC |
| 4736293. | 4736293 | [1] | BELT, TRANSMISSION | LECBELT |
| 4736401. | 4736401 | [1] | SUPPORT | LEC |
| 4736402. | 4736402 | [1] | ARM | LEC |
| 4736404. | 4736404 | [1] | BUSHING | LEC |
| 4736405. | 4736405 | [1] | PIN | LEC |
| 4736406. | 4736406 | [1] | WASHER | LEC |
| 4736408. | 4736408 | [2] | PIN | LEC |
| 4736409. | 4736409 | [1] | BELT TENSIONER | LECBELT STRETCHER |
| 4739709. | 4739709 | [1] | BELT, TRANSMISSION | LECBELT Superseded by part number: 4739708 |
| 4746893. | 4746893 | [1] | SPACER | LEC |
| 4756160. | 4756160 | [1] | BEARING ASSY | LECBEARING |
| 10517271. | 10517271 | [1] | LOCK WASHER,16.2mm ID x 27.7mm OD x 4mm Thk | BHBLOCKWASHER Superseded by part number: 10572173 |
| 10791421. | 10791421 | [1] | THIN NUT,Thin, M16 x 1.5, Cl 05 | MKT Superseded by part number: 10791411 |
| 11060575. | 11060575 | [1] | LOCKING RING | MKTLOCKRING Superseded by part number: 11060576 |
| 11198371. | 11198371 | [2] | BELLEVILLE WASHER,Belleville, M10.5 | MKTLOCKWASHER Superseded by part number: 11198374 |
| 12164711. | 12164711 | [2] | NUT,M10 x 1.25, Cl 8 | TTF Superseded by part number: 12164714 |
| 13453821. | 13453821 | [2] | STUD | BRE Superseded by part number: 13453824 |
| 14457680. | 14457680 | [1] | O-RING,0.103" Thk x 0.862" ID, -118, Cl 5, 75 Duro | BHB Superseded by part number: 14457681 |
| 76017908. | 76017908 | [1] | BELT | LEC |
