纽荷兰零件查询(FD20) - CRAWLER DOZER (B1.05[001]) - TORQUE CONVERTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
351 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 9920146. | 9920146 | [20] | SCREW | LEC Superseded by part number: 70923276 |
| 70186531. | 70186531 | [1] | SPACER | CMIWASHER |
| 70186563. | 70186563 | [1] | BEARING ASSY | CMIBEARING |
| 70656691. | 70656691 | [1] | WASHER | CMI |
| 70656776. | 70656776 | [1] | BEARING ASSY | CMIBEARING |
| 70657954. | 70657954 | [2] | SPACER | CMIRING |
| 70657955. | 70657955 | [1] | RING | CMIPLATE |
| 70665771. | 70665771 | [1] | RING | CMI Superseded by part number: 73119133 |
| 70668283. | 70668283 | [1] | BEARING ASSY | CMIWASHER |
| 70672955. | 70672955 | [1] | BEARING ASSY | CMIBEARING |
| 70687909. | 70687909 | [1] | IMPELLER | CMITURBINE |
| 70921768. | 70921768 | [1] | LOCK PIN,5.56mm OD x 15.88mm L, Slotted | LECTAPER PIN |
| 70922262. | 70922262 | [6] | SCREW | BHB Superseded by part number: 70929068 |
| 70922763. | 70922763 | [6] | SCREW | BHB Superseded by part number: 70929069 |
| 70923276. | 70923276 | [20] | SCREW,Hex, 3/8" - 24 x 1", Gr 8 | LEC |
| 79007210. | 79007210 | [1] | SEAL | LECO-RING |
| 79015849. | 79015849 | [1] | IMPELLER | LECPUMP Superseded by part number: 79028254 |
| 79015850. | 79015850 | [1] | IMPELLER | LECPUMP |
| 79015851. | 79015851 | [1] | HUB | LEC Superseded by part number: 9920146, 79051722, 79051719, 79051721, 79051720 |
| 79015854. | 79015854 | [1] | COVER | LEC Superseded by part number: 79028236 |
| 79015857. | 79015857 | [1] | PLATE | LEC Superseded by part number: 79028255 |
| 79015859. | 79015859 | [1] | PLATE | LEC |
| 79015864. | 79015864 | [1] | SCREW | LEC |
| 79018994. | 79018994 | [1] | HUB | LEC Superseded by part number: 79051722, 79051721 |
| 79028236. | 79028236 | [1] | SLEEVE | LEC |
| 79028254. | 79028254 | [1] | IMPELLER | LECPUMP |
| 79028255. | 79028255 | [1] | LOCKING PLATE | LECPLATE |
| 79051719. | 79051719 | [20] | WASHER | LEC |
| 79051720. | 79051720 | [1] | HUB | LEC |
| 79051721. | 79051721 | [1] | RING | LECLOCKRING |
| 79051722. | 79051722 | [1] | HUB | LEC |
