纽荷兰零件查询(FD20) - CRAWLER DOZER (B1.12/A[001]) - VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
232 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 581658. | 581658 | [1] | PLUG | MOD Superseded by part number: 5116017 |
| 8280351. | 8280351 | [1] | SPRING | LEC |
| 10303460. | 10303460 | [1] | GASKET | LECLINING |
| 10333910. | 10333910 | [1] | PIN | LEC |
| 13550201. | 13550201 | [1] | WASHER,6.15mm ID x 13mm OD x 1mm Thk | LEC Superseded by part number: 17094724 |
| 14330260. | 2852057 | [1] | SEALING WASHER,M8 x 12 x 1 Thk | TORLining M8 x 12 x 1 Thk |
| 14457681. | 14457681 | [1] | O-RING,0.103" Thk x 0.862" ID, -118, Cl 7, 75 Duro | TTF-118, Cl 7, .862" ID x .103" Thk |
| 79043953. | 79043953 | [1] | SEAT/SLOT | LECSEATING |
| 79043954. | 79043954 | [1] | PLUNGER | LEC |
