纽荷兰零件查询(FD20) - CRAWLER DOZER (F3.01[003A]) - CURRENT GENERATING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
168 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4976963. | 4976963 | [2] | PLATE | LEC |
| 10517071. | 10517071 | [4] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFIWASHER Superseded by part number: 10517073 |
| 10571871. | 10571871 | [1] | LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | LECWASHER, LOCK, M10 Superseded by part number: 10571873 |
| 10790111. | 10790111 | [1] | NUT,M10 x 1.25, Cl 8 | TTF Superseded by part number: 10790121 |
| 11112431. | 11112431 | [4] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 12646921. | 12646921 | [4] | WASHER,12.2mm ID x 28mm OD x 3mm Thk | BHB Superseded by part number: 16887624 |
| 76010818. | 76010818 | [1] | CAPPING | LECBEZEL |
| 76010819. | 76010819 | [1] | TIE-ROD | LECTIE ROD |
| 76010821. | 76010821 | [1] | CROSSRAIL | LECCROSS BEAM |
| 76010841. | 76010841 | [1] | SUPPORT | LEC |
| 79066003. | 79066003 | [1] | DRY BATTERY | LECBATTERY |
