神钢零件查询(F4HFE613S B003) - ENGNE 5801751514 - 47538794 (8/13-) (10.218.AI[01]) - INJECTION PIPE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
134 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854544 | [3] | INJECTION PIPE | TOR Superseded by part number: |
| 2. | 2854549 | [3] | INJECTION PIPE | TOR Superseded by part number: |
| 3. | 2854552 | [1] | INJECTION PIPE | TORASSY, Incl 4 - 7 Superseded by part number: |
| 5. | 2854556 | [2] | CLAMP BRACKET | TOR |
| 5. | 2854558 | [1] | RUBBER SEAL | TOR |
| 6. | 2854557 | [2] | CLAMP BRACKET | TOR |
| 6. | 2854555 | [1] | CLAMP BRACKET | TOR |
| 6. | 2855127 | [1] | CLAMP BRACKET | TOR |
| 7. | 2854559 | [2] | SCREW | TOR Superseded by part number: |
| 8. | 2853537 | [4] | BOLT,Hex Flange Head Cap M8 x 1.25 x 125mm | TOR Superseded by part number: 504053874 |
| 9. | 4896884 | [1] | BOLT,Flng, M8 x 1.25 x 16mm, Cl 10.9 | TORM8 x 1.25 x 16 |
| 9. | 4899020 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 10. | 2852434 | [1] | SPACER | TORSPACER-8.5I/DX18O/DX5LG Superseded by part number: 13605711 |
