纽荷兰零件查询(FD20) - CRAWLER DOZER (F4.01[003]) - CAB WIRING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
693 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4. | 70696279 | [1] | ECU | CMICIRCUIT BREAKER ASSY. |
| 4. | 70928182 | [2] | SCREW | CMICAPSCREW |
| 4. | 70919310 | [2] | WASHER | MKTLOCKWASHER Superseded by part number: 70904204 |
| 4. | 70911114 | [2] | WASHER | CMI Superseded by part number: 70928190 |
| 5. | 73124643 | [4] | CIRCUIT BREAKER | CMI |
| 6. | 70183714 | [2] | SWITCH | CMI |
| 7. | 70688313 | [3] | SWITCH | CMI |
| 8. | 73114689 | [1] | SWITCH | CMI |
| 11. | 73118599 | [1] | SPARE PART | CMIDOME LIGHT Superseded by part number: 73073392 |
| 13. | 73118605 | [2] | GROMMET | CMI |
