纽荷兰零件查询(FD20) - CRAWLER DOZER (F4.01/A[003]) - LIGHTING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
200 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 595208. | 595208 | [1] | WASHER | MOD |
| 4073976. | 4073976 | [1] | SWITCH | MKT Superseded by part number: 5109221 |
| 4073977. | 4073977 | [1] | BOOT | MKTINSULATING BOOT Superseded by part number: 5109222 |
| 10450090. | 10450090 | [1] | CLAMP,8mm, Coat, 9mm Bolt Hole, P Type | IMO |
| 10571771. | 10571771 | [2] | LOCK WASHER,M8 | CASLOCKWASHER Superseded by part number: 83990583 |
| 10571871. | 10571871 | [1] | LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | LECWASHER, LOCK, M10 Superseded by part number: 10571873 |
| 10788221. | 10788221 | [1] | NUT,M10, Cl 10 | LEC Superseded by part number: 86500689 |
| 11103031. | 11103031 | [1] | BOLT,Hex, M10 x 18, 10.9, Full Thd | LEC |
| 16043031. | 16043031 | [2] | BOLT,Hex, M8 x 12mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43231 |
| 76008164. | 76008164 | [1] | ELECTRIC CABLE | LEC |
| 79013422. | 79013422 | [6] | CABLE TIE,145mm L | LECSTRAP, CABLE, 145mm L |
| 79017173. | 79017173 | [1] | ELECTRIC CABLE | MODGROUND BRAID Superseded by part number: 79028421 |
| 79032280. | 79032280 | [2] | WRENCH | LECLOCK KEY Superseded by part number: 79073033 |
| 79038734. | 79038734 | [1] | NUT | LEC |
| 79038735. | 79038735 | [1] | SPRING WASHER | LEC |
| 79048326. | 79048326 | [1] | SWITCH | LEC Superseded by part number: 79073031 |
| 79073031. | 79073031 | [1] | SWITCH | LEC Superseded by part number: 47611853 |
| 79073033. | 79073033 | [2] | IGNITION KEY | LECLock Superseded by part number: 47611853 |
