纽荷兰零件查询(FD20) - CRAWLER DOZER (C1.01[003]) - BRAKE FOOT CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
945 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10112800. | 10112800 | [2] | CLIP | LECRETAINER |
| 10114100. | 10114100 | [1] | CLIP | LECRETAINER |
| 10516471. | 10516471 | [3] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 86517328 |
| 10979421. | 10979421 | [3] | SCREW,Hex, M6 x 10mm, Cl 8.8 | BHB Superseded by part number: 10979424 |
| 13407211. | 13407211 | [6] | LUBE NIPPLE,M10 x 1 | TTFNIPPLE, LUBE, M10 x 1 Superseded by part number: 84351730 |
| 79007731. | 79007731 | [2] | RIGID TUBE | LECPIPE |
| 79007733. | 79007733 | [1] | RIGID TUBE | LECPIPE |
| 79007735. | 79007735 | [2] | RIGID TUBE | LECPIPE |
