凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-48) - SPECIAL SHIELDS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
149 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3103101R1
|
[1] |
SHIELD
|
IH
ASSY, baler left
|
| . . |
160536
|
[5] |
SCREW,Cross Pan Hd, 1/4" - 20 x 5/8"
|
IH
Superseded by part number: 86511931
|
| . . |
109084
|
[2] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| . . |
103319
|
[2] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| . . |
95-11028
|
[2] |
WASHER,1/4"
|
CAS
.281 x .625 x .051 pln
|
| 2. |
203089C1
|
[1] |
SHIELD
|
IH
ASSY, packer gear upper
|
| 3. |
11309N
|
[2] |
SPACER
|
IH
knotter cover pivot
|
| . . |
19570R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 2
|
IH
1/4 x 5/8 type 1 Superseded by part number: 280641
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
120392
|
[2] |
WASHER,1/4", SAE
|
IH
.281 x .625 x .051 Superseded by part number: 87361
|
| 4. |
667787R1
|
[1] |
SPRING
|
IH
knotter cover
|
| . . |
110638
|
[2] |
RIVET
|
IH
3/16 x 5/16 pln but/hd sol
|
| 5. |
3102866R91
|
[1] |
COVER
|
IH
ASSY, knotter and drive arm
|
| 6. |
3102869R1
|
[1] |
FLANGE
|
IH
SEAL, flange knotter cover
|
| 7. |
3100615R1
|
[2] |
SPACER
|
IH
needle drive shield
|
| . . |
179848
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
IH
Superseded by part number: 88546
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
95-11041
|
[2] |
WASHER,3/8"
|
CAS
.406 x .812 x .051 pln Superseded by part number: 87016
|
