现代零件查询R210LC-7A ARM SAFETY LOCK SYSTEM(#0142-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
885 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
ARM SAFETY LOCK GROUP
|
|
| 1. |
31N6-52137
|
[1] |
ARM CYL-SAFETY VALVE
|
|
| 1. |
31N6-52138
|
[1] |
ARM CYL-SAFETY VALVE
|
|
| 1. |
31N6-52139
|
[1] |
ARM CYL-SAFETY VALVE
|
|
| 1-0. |
@
|
[1] |
ARM CYL SUB ASSY
|
|
| 1-1. |
31N6-90520
|
[1] |
VALVE-SAFETY LOCK
|
|
| 1-11. |
ZTAS-00001
|
[1] |
VALVE-RELIEF
|
|
| 1-12. |
ZTAS-00002
|
[1] |
CAP
|
|
| 1-13. |
P184-162112
|
[1] |
FLANGE-PLUGING
|
|
| 1-14. |
Y171-024004
|
[1] |
O-RING
|
|
| 1-15. |
S109-120406
|
[1] |
BOLT-SOCKET
|
|
| 1-16. |
ZTAS-00005
|
[1] |
SEAL KIT
|
|
| 1-2. |
31N6-90636
|
[1] |
PIPE ASSY-RV
|
|
| K1-4. |
Y171-024004
|
[2] |
O-RING
|
|
| 1-6. |
S107-120556
|
[8] |
BOLT-SOCKET
|
|
| 2. |
31N6-90660
|
[1] |
TERMIANL-SAFETY VLV
|
|
| 3. |
P910-062046
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 4. |
P930-062102
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 4. |
P930-062094
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 5. |
P930-042036
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-042102
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-042094
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
X511-104513
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 8. |
X500-110011
|
[1] |
CONNECTOR-ORFS
|
|
| 9. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 10. |
S552-020102
|
[20] |
CLAMP-BAND
|
|
| 31. |
S631-011004
|
[3] |
O-RING
|
|
| 32. |
S621-012001
|
[4] |
O-RING
|
|
| 33. |
S621-011001
|
[4] |
O-RING
|
|
| K. |
31Y1-18246
|
[1] |
SEAL KIT
|
|
