纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.02[006]) - HYDRAULIC SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
418 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10517171. | 10517171 | [12] | LOCK WASHER,14.2mm ID x 24.1mm OD x 3.5mm Thk | MKTLOCKWASHER Superseded by part number: 10572074 |
| 121164021. | 12164021 | [8] | NUT,Thick Hex, M14, 1.50mm Pitch, 11.00mm High, Cl 10, ZND | TTFM14 x 1.5, Cl 10 Superseded by part number: |
| 15979531. | 15979531 | [4] | SCREW,Hex, M14 x 1.5 x 200mm, Cl 10.9 | LEC |
| 15979831. | 15979831 | [4] | SCREW | LEC |
| 15979931. | 15979931 | [4] | SCREW | LEC |
| 76002036. | 76002036 | [2] | RIGID TUBE | LECPIPE |
| 76002037. | 76002037 | [1] | GUARD | LECPROTECTION Superseded by part number: 76009401 |
| 76002038. | 76002038 | [1] | GUARD | LECPROTECTION Superseded by part number: 76009400 |
| 76002046. | 76002046 | [4] | BRACKET | LEC |
| 76002047. | 76002047 | [2] | BRACKET | LEC |
