纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.02/1[001]) - HYDRAULIC SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
575 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10517071. | 10517071 | [20] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 10571871. | 10571871 | [8] | LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | LECWASHER, LOCK, M10 Superseded by part number: 10571873 |
| 11106630. | 11106630 | [8] | BOLT,Hex, M10 x 35mm, Cl 10.9, Full Thd | CMISCREW Superseded by part number: 11106631 |
| 11112231. | 11112231 | [2] | SCREW,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 398792 |
| 11113430. | 11113430 | [2] | BOLT,Hex, M12 x 60mm, Cl 10.9 | COESCREW Superseded by part number: 11113431 |
| 14463580. | 14463580 | [2] | O-RING,0.139" Thk x 1.17" ID, -217, Cl 5, 75 Duro | MKT |
| 76005005. | 76005005 | [1] | CYLINDER | LECOPERATING CYLINDERS Superseded by part number: 76007441 |
| 76007441. | 76016793 | [1] | CYLINDER | LECOPERATING CYLINDERS |
| 79034183. | 79034183 | [1] | SHIELD | LEC |
| 79034229. | 79034229 | [2] | FLEXIBLE HOSE | LECHOSE |
| 79035264. | 79035264 | [1] | RIGID TUBE,129, 61 mm Length | LECPIPE |
| 79035265. | 79035265 | [1] | RIGID TUBE,167, 61 mm Length | LECPIPE |
| 79065270. | 79035270 | [1] | GUARD | LECPROTECTION |
| 79035337. | 79035337 | [1] | CYLINDER | LECOPERATING CYLINDERS Superseded by part number: 76005005 |
