纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.02/3[001]) - HYDRAULIC SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
119 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8274816. | 8274816 | [2] | FLEXIBLE HOSE | MKTHOSE Superseded by part number: 79033024 |
| 8283424. | 8283424 | [2] | HOSE | LEC |
| 8284189. | 8284189 | [2] | FLEXIBLE HOSE | LECHOSE Superseded by part number: 8274816 |
| 8284300. | 8284300 | [2] | CYLINDER | LEC |
| 8284519. | 8284519 | [2] | HOSE | LEC Superseded by part number: 8284521 |
| 8284520. | 8284520 | [2] | RIGID TUBE | LECHOSE Superseded by part number: 8284521 |
| 8284521. | 8284521 | [2] | RIGID TUBE | LECHOSE |
| 8286385. | 8286385 | [1] | RIGID TUBE | LECPIPE |
| 8286390. | 8286390 | [1] | RIGID TUBE | LECPIPE |
| 8291117. | 8291117 | [2] | FLEXIBLE HOSE | LECHOSE |
| 8291122. | 8291122 | [2] | FLEXIBLE HOSE | LECHOSE Superseded by part number: 8284521 |
| 10516871. | 10516871 | [4] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10517070. | 10517070 | [8] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | MKTLOCKWASHER Superseded by part number: 10517071 |
| 14463680. | 14463680 | [4] | O-RING,0.139" Thk x 1.234" ID, -218, Cl 5, 75 Duro | TTFSEAL Superseded by part number: 14463681 |
| 15540931. | 15540931 | [8] | BOLT,Hex, M12 x 1.25 x 55mm, Cl 10.9 | TTFBOLT, Hex, M12 x 1.25 x 55, 10.9 |
| 79022512. | 79022512 | [1] | RIGID TUBE | LECPIPE |
| 79033024. | 79033024 | [2] | FLEXIBLE HOSE | LECHOSE |
| 11106221. | 11106221 | [4] | SCREW,Hex, M10 x 25mm, Cl 8.8, Full Thd | IMOBOLT, Hex, M10 x 25, 8.8, Full Thd Superseded by part number: |
