纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.05/2[001]) - DOZER BLADE CYLINDER MOUNTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
854 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8273892. | 8273892 | [2] | DISC | LECPLATE |
| 8284369. | 8284369 | [4] | BUSHING | LECBUSH |
| 8297992. | 8297992 | [2] | YOKE | LECSUPPORT |
| 10517271. | 10517271 | [8] | LOCK WASHER,16.2mm ID x 27.7mm OD x 4mm Thk | BHBLOCKWASHER Superseded by part number: 10572173 |
| 10839510. | 10839510 | [4] | DOWEL,M6 x 9 | TTF Superseded by part number: 17275310 |
| 11115631. | 11115631 | [4] | BOLT,Hex, M14 x 35, 10.9, Full Thd | LEC |
| 1119437. | 11119437 | [8] | BOLT,Hex, M16 x 75, 10.9 | LECSCREW |
| 14246100. | 14246100 | [2] | LOCKING PLATE | LECLOCKPLATE |
| 14465680. | 14465680 | [2] | O-RING,0.139" Thk x 3.484" ID, -238, Cl 5, 75 Duro | TTFSEAL Superseded by part number: 14465681 |
| 14465780. | 14465780 | [2] | O-RING,0.139" Thk x 3.609" ID, -239, Cl 5, 75 Duro | BHB-239, 70 Duro, 3.609" ID x .139" Thk Superseded by part number: |
| 76004584. | 76004584 | [2] | YOKE | LECSUPPORT Superseded by part number: 8297992 |
| 76004596. | 76004596 | [2] | GASKET | LECLINING |
