纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.10[001]) - DOZER BLADE LIFTING ARMS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
209 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8284460. | 8284460 | [2] | HALF-BUSHING | LECHALF BUSH |
| 8284461. | 8284461 | [4] | PLATE | LEC |
| 8298325. | 8298325 | [2] | SUPPORT | LEC |
| 8299778. | 8299778 | [1] | U-FRAME | LECPUSH-FRAME Superseded by part number: 76020119 |
| 8299780. | 8299780 | [2] | PAD | LEC |
| 10517671. | 10517671 | [4] | LOCK WASHER,24.3mm ID x 39.8mm OD x 5.5mm Thk | MODLOCKWASHER Superseded by part number: 10572571 |
| 12163721. | 12163721 | [4] | NUT,M24, Cl 10 | LEC Superseded by part number: 9848973 |
| 16162537. | 16162537 | [4] | BOLT,Hex, M24 x 3 x 200mm, Cl 10.9 | LECSCREW Superseded by part number: 16162534 |
