沃尔沃零件查询MD120A; MD120AK; TMD120A; TMD120AK; TAMD120A; TAMD120AK; TMD120B; TAMD120B; TAMD120B-CCEngineCylinder BlockEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
466 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
468702
|
[1] |
Cylinder block
|
Replaced by cylinder block 478990 and 6 pcs cylinder liner kit 275392.
|
| 1. |
478990
|
[1] |
Cylinder block
|
|
| 2. |
422426
|
[1] |
Pivot pin
|
|
| 3. |
|
|
|
|
| |
423444
|
[14] |
Flange screw
|
|
| 5. |
422076
|
[1] |
Bushing
|
|
| 6. |
422077
|
[1] |
Bushing
|
|
| 7. |
422078
|
[1] |
Bushing
|
|
| 8. |
422079
|
[1] |
Bushing
|
|
| |
422080
|
[1] |
Bushing
|
|
| 10. |
422081
|
[1] |
Bushing
|
|
| 11. |
422082
|
[1] |
Bushing
|
|
| 12. |
467367
|
[5] |
Plug
|
(467649)
|
| 13. |
469328
|
[6] |
Gasket
|
|
| 14. |
942734
|
[2] |
Plug
|
|
| 15. |
422369
|
[7] |
Plug
|
|
| 16. |
821335
|
[1] |
Plug
|
|
| 17. |
952077
|
[1] |
Plug
|
|
| 18. |
|
|
|
|
| |
925060
|
[1] |
O-ring
|
|
| 20. |
955524
|
[2] |
Hexagon screw
|
|
| 21. |
941907
|
[2] |
Spring washer
|
|
| 22. |
955083
|
[3] |
Cap plug
|
|
| 23. |
952077
|
[5] |
Plug
|
|
| 24. |
955082
|
[3] |
Cap plug
|
|
| 25. |
16318
|
[3] |
Plug
|
|
| |
907132
|
[3] |
Gasket
|
|
| 27. |
190798
|
[1] |
Plug
|
|
| 28. |
18818
|
[1] |
Gasket
|
|
| |
423120
|
[2] |
Inspection cover
|
|
| 30. |
467409
|
[2] |
Gasket
|
|
| 31. |
422541
|
[4] |
Shoulder screw
|
|
| 32. |
424342
|
[4] |
Sealing ring
|
|
| 33. |
423121
|
[1] |
Inspection cover
|
|
| 34. |
422542
|
[1] |
Splash plate
|
|
| 35. |
467409
|
[1] |
Gasket
|
|
| 36. |
422541
|
[2] |
Shoulder screw
|
|
| 37. |
424342
|
[2] |
Sealing ring
|
|
| 38. |
843368
|
[1] |
Breather pipe
|
|
| 39. |
421158
|
[2] |
Sealing ring
|
|
| 40. |
843366
|
[1] |
Bracket
|
|
| |
940114
|
[3] |
Hexagon screw
|
|
| 42. |
942336
|
[3] |
Spring washer
|
|
| 43. |
843356
|
[1] |
Connecting box
|
|
| 44. |
955529
|
[2] |
Hexagon screw
|
|
| 45. |
941907
|
[2] |
Spring washer
|
|
| |
955826
|
[2] |
Hexagon nut
|
|
| 47. |
843736
|
[1] |
Filter
|
|
| 48. |
843449
|
[1] |
Gasket
|
|
| 49. |
924058
|
[1] |
Stud
|
|
| 50. |
842972
|
[1] |
Valve disc
|
|
| 51. |
842974
|
[1] |
Spacer sleeve
|
|
| 52. |
843301
|
[1] |
Spring
|
|
| 53. |
842975
|
[1] |
Protecting casing
|
|
| 54. |
421158
|
[1] |
Sealing ring
|
|
| 55. |
963105
|
[1] |
Lock nut
|
|
| |
190130
|
[1] |
Reduction nipple
|
|
| 57. |
949918
|
[1] |
Shut-off cock
|
|
| 58. |
836993
|
[1] |
Nipple
|
See group 2B
|
| |
468539
|
[6] |
Oil jet
|
|
| |
948587
|
[6] |
Hexagon screw
|
|
| |
842830
|
[1] |
Tube
|
See group 2B
|
| 62. |
190714
|
[1] |
Hollow screw
|
See group 2B
|
| |
957181
|
[1] |
Gasket
|
|
| 64. |
956985
|
[1] |
Fitting nut
|
|
| 65. |
956971
|
[1] |
Ferrule
|
|
| |
192639
|
[1] |
Nipple
|
|
| 68. |
843529
|
[1] |
Housing
|
|
| |
925065
|
[2] |
O-ring
|
|
| 70. |
468838
|
[1] |
Valve
|
|
| 71. |
940094
|
[2] |
Hexagon screw
|
|
| 72. |
941906
|
[2] |
Spring washer
|
|
| 73. |
952629
|
[1] |
Clamp
|
|
| 74. |
940100
|
[1] |
Hexagon screw
|
|
| |
955525
|
[2] |
Hexagon screw
|
|
| |
941907
|
[2] |
Spring washer
|
|
| 77. |
845260
|
[1] |
Hose attachment
|
|
