| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 290-1993 | [2] | STRAP-CABLE | |
| 2. | 349-7699 | [1] | BRACKET | |
| 3. | 101-3129M | [1] | STUD(M10X1.5-THD) | |
| 4. | 362-1505Y | [1] | HARNESS AS-SENSOR(COOLANT TEMPERATURE) | |
| 5. | 4P-7581 | [1] | CLIP(LADDER) | |
| 6. | 6V-5215M | [1] | BOLT(M8X1.25X16-MM) | |
| 7. | 6V-5839 | [1] | WASHER(11X21X2.5-MM THK) | |
| 8. | 9M-1974 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION | |||
